Key Specs

Motherboard Support:E-ATX (Up to 27.7mm), ATX, Micro-ATX, Mini-ITX

Enclosure Type:Mid-Tower

Case Material:SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted Tempered Glass (Black)

Dimensions

Height (with feet):544 mm

Width:244 mm

Depth:468 mm

Weight:11.13 kg

Compatibility & Clearance

CPU Cooler Height:Up to 185 mm

GPU Length:Up to 410 mm

PSU Length:Up to 200 mm

Cable Management:Up to 34.5 mm

Top Mounted 140mm / 280mm Radiator & Fan Combined Thickness:Up to 57 mm

Front I/O Ports

USB 3.2 Gen 1 Type-A:2

USB 3.2 Gen 2 Type-C:1

Headset Audio Jack:1

Expansion Slots

Standard:7

Vertical:0

Drive Bays

2.5″:2+2

3.5″:2

Fan Support

Front:3 x 120 mm / 3 x 140 mm (3 x F120Q included)

Top:3 x 120 mm / 2 x 140 mm

Rear:1 x 120 mm / 1 x 140 mm

Filters:High-Performance Mesh

Radiator Support

Front:Up to 420 mm

Top:Up to 360mm

Rear:Up to 140mm

Fan Specs

Model:F120Q Airflow Fan (Case Version)

Speed:1,350 ± 150 RPM

Airflow:60.2 CFM

Static:1.05 mm – H2O

Noise:24.1 dBA

Fan Connector:3-pin

General

Warranty:2 Years

Model Number:CM-H72FB-01 (Black) / CM-H72FW-01 (White)

UPC:810074845557 (Black) / 810074845564 (White)

EAN:5056547205502 (Black) / 5056547205519 (White)
